Garanţie: 12 luni
- Descriere
- Caracteristici
- Download (1)
- Review-uri (0)
Ventilator Axial de Presiune inalta, pentru tubulatura, rotor din aluminiu turnat de inalta performanta, cu debite cuprinse intre 13850 si 156 800 mc/h. Carcasa - Tabla groasa din Otel
Motor:
- Motoare clasa F cu rulmenti cu bile, protectie IP55;
- Trei faze 230/400V.-50Hz ( pana la 5.5CV ) , 400/690V.-50Hz . ( putere peste 5.5CV . )
- Temperatura de lucru: -20ºC.+ 70ºC.
- Motoare cu doua viteze monofazate eficienta IE - 2 , cu exceptia motoarelor mai mici de 0,75 kW
Finisaj:
- Protectie Inalta - Otel Anticoroziune, , Vopsea de inalta calitate pentru medii corozive
Debit aer (mc/h): Intre 40001-50000
Diametru ( mm ): 710
Alimentare electrica (V/Hz): 690V/50Hz, 400V/50Hz
Rotatii/minut: 2950
Greutate (Kg): 225
Etichete: ventilator sodeca, ventilator de tubulatura, ventilatoare sodeca, HTP-71-2T-30, VENTILATOR AXIAL PRET, VENTILATOARE DE TUBULATURA, VENTILATOARE AXIALE DE TUBULATURA, VENTILATOR AXIAL, VENTILATOARE AXIALE
Detalii:
-
Ventilator Axial de Tubulatura HTP
Descarca
